Oscillating granulator is used for gentle homogenization, size reduction, grading and sieving of dry, sensitive powders and granules in pharmaceutical, chemical and food industries. Oscillating Granulator has one rotor with five edge, which oscillate on horizontal axis at about 180 per minutes. There is one half round sieve mounted at the bottom of the rotor. Product is charged from the top through in feed hopper and material falls on the rotor lades. The particles are broken by a set of oscillating bars arranged in cylindrical form over a screen of suitable mesh. Due to the sharp edges on rotor, the downsizing of particle takes place and through sieve material gets pushed outward from the bottom opening. SALIENT FEATURES:
- High speed uniform granulation by oscillating motion of rotor.
- Design is cGMP – Current Good Manufacturing Practices compliance.
- All contact parts AISI 316 & non contact parts AISI 304.
- Easy to operate; move, clean, convenient, online granulation & user friendly.
- Uniformly granulation & fewer fines.
- Zero dusting & maintenance free.
- Safety feature: Limit switch at charging hopper & over load relay protection.
- Option for online granulation with Roll compactor, Rapid Mixer Granulator & Bowl of Fluid Bed Dryer by tipper.
TECHNICAL SPECIFICATIONS:
|
MODEL
|
POG-250
|
POG-500
|
|
Output
|
Up to 250 Kg / Hour
|
Up to 500 Kg / Hour
|
|
Oscillating Speed
|
180 per minute
|
180 per minute
|
|
Motor
|
2 hp
|
2 hp X 2 Nos.
|
|
Power
|
1.5 Kw/3 ph/415 V/50 Hz
|
3 Kw/3 ph/415 V/50 Hz
|
|
