Automatic ROPP Cap Sealing Machine - Single Head

Automatic ROPP Cap Sealing Machine - Single Head

Get a Price/Quote

Product Details:

  • Material Stainless Steel
  • Capacity 30-400 Kg/hr
  • Voltage 220-410 Watt (w)
  • Click to View more
Request to Call Back Send Inquiry
X

Automatic ROPP Cap Sealing Machine - Single Head Price And Quantity

Automatic ROPP Cap Sealing Machine - Single Head Product Specifications

  • 30-400 Kg/hr
  • 220-410 Watt (w)
  • Stainless Steel

Automatic ROPP Cap Sealing Machine - Single Head Trade Information

  • Cheque
  • 1 Per Day
  • 1-12 Week
  • Box
  • Australia North America South America Eastern Europe Western Europe Middle East Africa Asia Central America
  • All India

Product Description

Application & Process:

Single Head, Automatic ROPP Cap Sealing Machine is perfect for sealing bottles in pharmaceuticals, agro chemicals, dairy, food and beverages industries. The system is designed to be versatile and compact in nature. And the unit is enclosed in stainless steel body with matt finish. It consists cap feeding unit, automatic conveyer belt, single head capping unit with cam & gear motor drive. There is automatic movement of filled bottle toward the capping head on a slat belt. During the movement, it picks cap from the feeding unit (rotating type). The capping head moves up and down with revolution to thread, on cap to bottle sealing. After sealing, it moves the bottle for further activity on conveyer.

Salient Features:
  • No need of container & cap system.
  • Easy adjustment of sealing pressure, for different size of caps & gauges.
  • Low power consumptions & low noise level.
  • Adaptable conveyor belt height, for easy match with other machines of the line.
  • Adjustable bottle height gauge for quick, easy setting.
  • Synchronized A/C drives for conveyor, platform turret, star wheel & capping bowl.
  • Self-lubricating UHMW PE guide profile offers low friction wears surface, and smooth conveying.

Model PASRCS-60
Output/Hour* 1000 to 3000 Bottles
Direction of Movement Left to Right
No. Of Sealing Head 1 Nos.
Power** Consumption Main Motor 1 HP / 415 Volts / 50Hz
Cap Feeding Bowl 300 Watt



Other Products in 'Filling And Packaging Lines' category

Automatic Screw Cap Sealing Machine - Single Head
Send Inquiry
Linear Bottle Washing Machine
Send Inquiry
Automatic Multi Head Cap Sealing Machine: ROPP/ Screw
Send Inquiry
Turntable Machine
