Capsule Filling Sealing Machine
nan INR
Product Details:
- Type Capsule Filing Machine
- Material Stainless Steel
- Capacity 30-400 Kg/hr
- Computerized Yes
- Control Mode Automatic
- Voltage 220-410 Watt (w)
- Power 210-310 Volt (v)
- Click to View more
X
Capsule Filling Sealing Machine Price And Quantity
- 1 Unit
- nan INR
Capsule Filling Sealing Machine Product Specifications
- Stainless Steel
- 30-400 Kg/hr
- Silver
- Yes
- Capsule Filing Machine
- Yes
- 220-410 Watt (w)
- Automatic
- 400-600 Kilograms (kg)
- 210-310 Volt (v)
Capsule Filling Sealing Machine Trade Information
- Cheque
- 1 Unit Per Day
- 1-12 Week
- Box
- Western Europe Australia Eastern Europe Middle East South America Asia Central America North America Africa
- All India
Product Description
The semi automatic Capsule Filling Sealing Machine is user friendly with advanced features. It is designed for precision manufacturing Requirements of modern pharmaceutical procedures. The machine provides a high Degree of automation with higher levels of filling weight accuracy. These machines are suitable for filling capsule of all size with powder, pellets and granules.
Salient Features:
- Design is cGMP Current Good Manufacturing Practices compliance.
- Auto drug hoppers in feed mechanism reduce weight variation and improve productivity.
- All contact parts AISI 316 & non contact parts AISI 304.
- A choice of four-auger with a variable speed of filling table provide flexibility achieve accurate weight.
- Capsule holding dish with aluminum MOC.
- Simple structure and low malfunction easy to maintain.
Technical Specification:
| Model | Single Head Machine |
| Output | 25,000 of 30, 000 capsule per/hour |
| Electrical main drive | 1 HP, 440 Volts, 50 HZ, 700 rpm |
| Filling drive with reduction gear box | 0.5 HP 440 Volts, 3 phase, 50 HZ, 1440 |
| Vacuum pump motor | 3 HP, 440 Volts, 3 phase, 50 HZ, 1440 rpm |
| Vacuum | 500 mm (20) of Hg at 1000 Liters /min (30cmf) |
| Compressed Air | 200 Liters/min (8 cfm) at 100 psi |
| Dimension | 1650 mm* 1250 mm* 1650mm* (L*W*H) |
| Net Weight | 550 Kg approx |
