Turn Table
Product Details:
- Material Stainless Steel
- Capacity 30-400 Kg/hr
- Voltage 220-410 Watt (w)
- Click to View more
X
Turn Table Price And Quantity
Turn Table Product Specifications
- Stainless Steel
- 30-400 Kg/hr
- 220-410 Watt (w)
Turn Table Trade Information
- Cheque
- 1 Per Day
- 1-12 Week
- Box
- Western Europe Eastern Europe Middle East Central America Africa South America Australia Asia North America
- All India
Product Description
Process and Application:Stainless steel un scrambler and scrambler that is same as our turn table, which is constructed on reduction gear box, solid guide rail and SS square frame for noiseless and jerk less performance. Our table is beneficial to ensure uniform container flow, take 90o turn and complete synchronization to match various applications and machine in mechanical liquid line. Container inputs are made in our turn table by automatically or manually that will revolve on disk and exit via outlet amid container rotation, which is directed by SS strip. Further, the SS strip direct the container to outlet path.
Key Features:
- 20’’, 36’’, 30’’ and 46’’ diameter tables are available
- Triple step pulley is offered for various speed
- Special auto-adjusting bearings guarantee convenient working
- Appropriate for various container type
- SS beautifully matt finished structure
- 0.5 HP minimization gear motor assures silent and jerk safe working
- Changeable speed drive
- Lock castor wheel
- Acrylic cover
- Tray for container unloading or loading
