Lab Automatic Tablet Coater
nan INR
Product Details:
- Type Lab Automatic Tablet Coater
- Material Stainless Steel
- Capacity 200-250 Kg/hr
- Computerized Yes
- Control Mode Automatic
- Voltage 220-340 Volt (v)
- Power 410-440 Volt (v)
- Click to View more
X
Lab Automatic Tablet Coater Price And Quantity
- nan INR
- 1 Piece
Lab Automatic Tablet Coater Product Specifications
- Stainless Steel
- Yes
- Silver
- Yes
- 275-425 Kilograms (kg)
- 410-440 Volt (v)
- Automatic
- Lab Automatic Tablet Coater
- 220-340 Volt (v)
- 200-250 Kg/hr
Lab Automatic Tablet Coater Trade Information
- Cheque
- 1 Piece Per Day
- 1-12 Week
- Box
- Western Europe Australia Eastern Europe Central America Africa Middle East South America Asia North America
- All India
Product Description
In the year 2005 our company was inaugurated as a leading manufacturer and exporter of Lab Automatic Tablet Coater. It is manufactured by making use of quality tested materials and highly advanced technology. This is used for coating the tablets in laboratory. Furthermore, our esteemed customers can avail this Lab Automatic Tablet Coater from us at industry leading prices.
Features:
Features:
- Optimum performance
- Less maintenance
- Easy to operate
New Design Features
- Designed strictly compliance with the stipulation of cGMP.
- Product contact parts AISI 316/ 316 L Quality.
- Complete automatic coating processes with advanced PLC Controls with HMI touch Screen.
- Perforated coating pan with mixing baffles, anti slide ribs and variable speed by VFD.
- Enclosed pan drive through reduction gear box and motor.
- All doors, safety guards and covers are provided with a suitable food grade seals.
- The perforated pan has a suitable mouth opening for tablet Charging and Discharging which provided with stainless steel cover and a glass window for process visualization.
- Front Entry stainless steel arm, with facility to adjust the angle of spray guns is provided.
- Atomized Spraying system with solution holding tank, peristaltic pump, atomized spray gun and auto electro-pneumatic spraying controls system through PLC
- Inbuilt Inlet Air handler with blower, electric heater, 20 & 5 micron filter & 0.3 micron HEPA.
- Inbuilt Exhaust air blower with 20 micron filter.
- Inlet air flow and exhaust air flow can be adjusted through variable speed of blower by VFD.
- Differential pressure indicator for pan and HEPA filter.
- WIP system for easy cleaning
- Option for Interchangeable pan.
- Explosion proof electric motor.
- Auto shutoff system for over limit temperature/ heating.
- Auto stop when process is completed.
- Air pressure switch installed to ensure pressure is in limit.
- Differential pressure indicator for HEPA Filter.
- Safe earthing system for static current.
- Overload relay controls.
| MODEL | LABOcoata- 12 | LABOcoata -20 Interchange pan | LABOcoata-20 | LABOcoata- 24 | ||||
| Pan Diameter | 12"-300 mm | 20" maximum | 20" ( 508) | 24"( 610) | ||||
| Interchangeable | NO | 12" 300 | 14" 355 | 16" 406 | 18" 458 | 20" 508 | NO | NO |
| Pan Drum - RPM | 4 to 20 | 4 to 20 | 4 to 20 | 4 to 20 | ||||
| Pan Opening Dia. mm | 150 | 150 | 150 | 200 | 200 | 225 | 225 | 250 |
| Pan Working Load Kg | 1 | 1 | 3 | 4.5 | 10 | 18 | 18 | 27 |
| Anti-slide ribs | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 |
| Mixing Baffles | 2 | 2 | 4 | 4 | 4 | 4 | 4 | 6 |
| Pan Drive Hp/kw | 0.5 / 0.37 | 1 / 0.75 | 1 / 0.75 | 1.5 /1.12 | ||||
| Inlet Air Blower HP / cfm | 1/ 150 | 2 / 1000 | 2 / 1000 | 3 / 1200 | ||||
| Exhaust Air Blower/cfm | 1/ 150 | 2 /1000 | 2 / 1000 | 3 /1200 | ||||
| Peristaltic Pump HP/kw | 0.25 / 0.18 | 0.25 / 0.18 | 0.25 / 0.18 | 0.25/ 0.18 | ||||
| Electric Heater - Kw | 6 | 12 | 18 | 22 | ||||
| Spraying gun | 1 No. | 1-2 nos. | 2 nos. | 2 nos. | ||||
| Machine size L XW XH | 100 X100X120 cm | 100 X100X120 cm | 100 X100X120 cm | 100 X100X120 cm | ||||
