Conventional Coating Machine
3 Lakh INR
Product Details:
- Product Type Conventional Coating Machine
- General Use For Industry
- Material Stainless Steel
- Weight (kg) 520-600 Kilograms (kg)
- Computerized Yes
- Automatic Yes
- Power Source Electric
- Click to View more
X
Conventional Coating Machine Price And Quantity
- 3 Lakh INR
- 1 Unit
Conventional Coating Machine Product Specifications
- 520-600 Kilograms (kg)
- Electric
- For Industry
- 220-410 Watt (w)
- Yes
- Conventional Coating Machine
- Silver
- Yes
- Yes
- Stainless Steel
Conventional Coating Machine Trade Information
- Cheque
- 1 Unit Per Day
- 1-12 Week
- BOx
- Western Europe Central America Africa Eastern Europe Middle East South America Australia Asia North America
- All India
Product Description
Conventional coating machines are used to sugar coat tablets, pills, etc in for a variety of industries such as Pharmaceutical, Confectionery, Food and others. They are also used for rolling and heating beans and edible nuts or seeds.The product is to be filled inside the pan. During the rotation motion, coating material is sprayed by spraying system according to the technological process and rational technological process. So process materials (product) are coated due to rotating pan. The coating round pot is rotated by variable speed. At the same time hot air is supplied through inbuilt Hot air blower system which dries rapidly (heating or cooling) and evenly thus forming a solid and smooth surface.
SALIENT FEATURES:
- Design is cGMP Current Good Manufacturing Practices compliance.
- All contact parts AISI 316 & non contact parts AISI 304.
- Conventional coating system for manual film coating and sugar coating.
- Easy to replace polishing pan and other size coating pan.
- Machine is designed with fabricated structure fitted with SS enclosure which makes simple, cleanable outside covering and mounted on anti vibration pad.
- Closed powerful drive with reduction gearbox and motor by variable speed pulley.
- Along with movable hot air blowing system.
- Option for Atomized Spraying System with Spray Gun, Peristaltic Pump, Solution tank and Electro Pneumatic controls.
- Optional Features: AC frequency drive for Pan, detachable baffle, explosion proof motor,
TECHNICAL SPECIFICATIONS:
| MODEL | PCP-30 | PCP 36 | PCP-42 | PCP-48 | PCP-60 | PCP-72 |
| Pan Size | 30 | 36 | 42 | 48 | 60 | 72 |
| Loading Capacity in Kg | 45 | 80 | 100 | 150 | 210 | 275 |
| Pan Angle | 30o | 30o | 30o | 30o | 30o | 30o |
| Pan RPM | 8 to 15 | 8 to 15 | 8 to 15 | 8 to 15 | 8 & 12 | 8 & 12 |
| Pan motor HP | 1.5 | 1.5 | 2 | 2 | 5 | 5 |
| Blower motor HP | 1 | 1 | 1 | 1 | 1 | 1 |
| Blower capacity CFM | 150 | 150 | 150 | 150 | 150 | 150 |
| Heater Capacity in Kw | 6 | 6 | 6 | 6 | 6 | 6 |
